Vine Haven *
|
Category: |
Single Family Dwelling (Private Residence) |
|
SKU: |
260406a |
|
Price: |
$30 |
|
Bedrooms: |
3 |
|
Baths: |
2.5 |
|
Heated Square Feet: |
2020 |
|
Unheated Square Feet: |
1112 |
|
Total Square Feet: |
3132 |
|
Style: |
French Country |
|
Levels: |
1 Story |
|
Covered Parking: |
Carport - 1 car, Porte Cochere |
|
Width: |
69' |
|
Depth: |
64' |
|
Height: |
24' |
|
Ceiling Height (Notes): |
10'-0", 11'-0", 12'-0", Trey ceiling (as indicated), Vaulted ceiling (as indicated) |
|
Roof Pitch: |
4:12, 12:12, 16:12 |
|
Roof Type: |
Gable, Shed (Skillion) |
|
Key Words: |
Attic Storage, Fireplace - Gas, Mud, Pantry |
|
Foundation Type: |
Stem Wall Foundation |
|
Exterior Wall Type: |
2x6 Wood Studs |
|
Collaborations with: |
T Draft, Abram Homes |
|
Set type: |
This plan is currently only offered as a SCHEMATIC STUDY SET only and is not intended for construction. A complete construction drawing set has not yet been developed into a full construction document package. For construction documents with or without custom modifications, please contact us at tina@tdraft.net |
|
{{variant.name}}:
|
{{opt.name}}
{{opt.name}}
|
schematic only available
